PRODUCT INTRODUCTION

· The steel plate radiator is butt welded with sink pressed by high-quality cold-rolled tensile steel plate. The single plate, double plate and triple plate are connected together by connecting bend or tee. The convection piece is welded on the back of the radiator in order to improve the effect. The discharge grille is installed to improve the beauty of radiator. The radiating effect is the best when cover plates are installed on both sides. The product is decorative, elegant, graceful, and easily installed and maintained, so it’s widely used in hot water heating system in constructional engineering. The product is 300-900mm high and 300-3000mm long.

· The steel plate radiator is not only used in two-pipe heating system with thermostat valve and one-pipe cross-over heating system, but also used in various conventional independent heating systems. The circulating water and supplementing water in central heating system shall be properly processed. The PH shall be 95-115, and oxygen content shall be no more than 0.1mg/L. The radiator shall be filled with water in non-heating period to increase its service life.

Product Advantages

· The non-carbonate nanotechnology is firstly adopted in radiator industry, the anti-corrosion performance of which is twice that of pickling and phosphating. The radiator’s service of life is greatly prolonged and its radiating effect is high;

· Its unique groove patent design ensures the difference of reasonable turbulent recurrent state, which greatly improves the radiating effect;

· The full-height radiating fin increases the radiating area of the radiator, which ensures a higher heat radiation amount;

· The raindrop-like head cover increases the heat radiation amount, which avoids the phenomenon of “smoked wall”.

Excellent Materials

· The materials of TEHEDE radiator are excellent. All the materials are high-quality low-carbon cold-rolled steel plates (carbon content ≤0.25%), which totally meet the EU standard.

· The materials have high plasticity and toughness, especially the cold deformation plasticity. The radiator has smooth surface, fine and uniform pipe wall structure, high pressure resistance, excellent welding performance, and great corrosion resistance.

10 Years’ Quality Assurance

· We promise to repair or exchange the radiators which have quality problems due to defects of materials or manufacturing in 10 years since the installation.
